Specifications
|
||
|---|---|---|
| Manufacturer | APC by Schneider Electric | |
| Model | AR3157X617 | |
| Product Line | NetShelter SX | |
| Rack Height | 48U | |
| Rack Width | 19″ EIA‑310 standard | |
| External Dimensions (H × W × D) | 2258 mm × 750 mm × 1070 mm | |
| Net Weight | Approx. 130–150 kg (varies by configuration) | |
| Shipping Weight | Depends on packaging | |
| Mounting Depth (Min–Max) | Approx. 191 mm – 915 mm | |
| Static Load Capacity | Up to ~1700 kg (3750 lbs) | |
| Dynamic Load Capacity | Up to ~1020 kg (2250 lbs) | |
| Front Opening | Open frame (no front door) | |
| Rear Opening | Open frame (no rear door) | |
| Vertical Rails / Posts | 14‑gauge EIA‑310 mounting rails | |
| Roof / Top Panel | 18‑gauge steel | |
| Side Panels | Not included | |
| Protection Rating | IP20 | |
| Color | Black | |
| Included Components | Roof, casters, leveling feet, baying hardware, mounting hardware (no sides or doors) | |
| Compliance Standards | EIA‑310E, UL 2416, UL 60950‑1 | |
|
