Feature | Description |
---|---|
Type | Access Switch |
PoE | Non-PoE |
Number of ports | 48 10/100/1000BASE-T Ethernet ports |
Uplink ports | 4 10 Gigabit Ethernet uplink ports |
PoE budget | N/A |
Switching capacity | 480 Gbps |
Packet forwarding rate | 355 Mpps |
MAC address table size | 320,000 |
IPv4 routing table size | 128,000 (indirect + direct) |
IPv6 routing table size | 128,000 (indirect + direct) |
Dimensions (WxDxH) | 17.5 x 17.5 x 1.73 inches |
Weight | 14.3 lbs (6.5 kg) |
Operating temperature | 32 to 122°F (0 to 50°C) up to 5,000 ft (1,524 m) |
Storage temperature | -13º to 158ºF (-25º to 70ºC) up to 15,000 ft (4,572 m) |
Operating relative humidity | 5% to 90% (noncondensing) |
Storage relative humidity | 5% to 95% (noncondensing) |
Power Requirements | Power Rating (maximum consumption): 85 watts |
Current | 4.2 amps |
