Technical Specification
|
Model |
E010GIT31 |
|
|
Capacity |
10000 VA / 10000 W |
|
inPUT
|
Nominal Voltage |
208*/220/230/240 VAC |
|
Input Voltage Range |
110~300VAC ± 3 % at 50% Load, 176~300VAC ± 3 % at 100% Load |
|
Frequency Range |
46~54 Hz or 56~64 Hz |
|
Power Factor |
≧ 0.99 @ Full Load |
OUTPUT
|
Output Voltage |
100*/110*/115*/120/127 VAC or 200*/208*/220/230/240 VAC |
|||
|
Power Factor |
0.9PF |
|||
|
Voltage Regulation |
± 1% |
|||
|
Output Frequency |
Line Mode |
57 ~ 63 Hz or 47 ~ 53 Hz |
||
|
Battery Mode |
(60Hz ± 0.1Hz or 50 Hz ± 0.1Hz |
|||
|
Crest Factor |
3:1 (max.) |
|||
|
Harmonic distortion (THDv) |
≦1 % THD (Linear Load), ≦ 4 % THD (Non-linear Load) |
|||
|
≦1 % THD (Linear Load), ≦ 4 % THD (Non-linear Load) |
||||
|
Transfer Time |
AC Mode to Battery Mode |
|
||
|
Inverter to Bypass |
Zero |
|||
|
Waveform (Batt. Mode) |
Pure Sinewave |
|||
