Specifications
|
||
|---|---|---|
| Fiber Count | Simplex (1-fiber) | |
| Connector Type | SC to SC | |
| Polish | APC to APC | |
| Cable Length | 1m,2m,3m … 50m or Customize | |
| Cable Diameter | 2.0 mm | |
| Tensile Strength | 50 N | |
| Length Tolerance | +/- 1cm | |
| Insertion Loss | ≤0.2dB | |
| Return Loss | ≥60dB | |
| Repeatability | ≤0.2dB | |
| Interchangeability | ≤0.2dB | |
| Jacket Material | LSZH (Low Smoke Zero Halogen) | |
| Jacket Color | Yellow | |
| Environment | Operating: -20°C to 70°C Storage: -40°C to 85°C | |
| Compliance | Telcordia GR-326-CORE RoHS compliant | |
| Application | Optical fiber communications system Optical fiber access networks Optical fiber CATV Optical fiber test equipment Optical fiber data communication | |
| Application | Premises Distribution Local Area Networks (LAN) Fiber-to-the-Home (FTTX) Device Terminations | |
|
