Category | Specification |
---|---|
Mechanical Dimensions | 442 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
Weight | Without mounting brackets: 4.5 kg (10 lb) |
With mounting brackets: 4.6 kg (10.2 lb) | |
Enclosure Material | SGCC steel |
Management Interface | Ethernet In-Band |
Networking Interfaces | (48) GbE RJ45 ports |
(4) 1G SFP ports | |
PoE Interface | (32) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
Total Non-Blocking Throughput | 52 Gbps |
Switching Capacity | 104 Gbps |
Forwarding Rate | 77.38 Mpps |
Power Method | Universal input, 100—240V AC, 50/60 Hz |
Power Supply | AC/DC, internal, 240W |
Supported Voltage Range | 100—240V AC |
Max. Power Consumption | 45W (Excluding PoE output) |
Total Available PoE | 195W |
Max. PoE Wattage per Port by PSE | PoE+: 32W |
Voltage Range PoE Mode | PoE: 44—57V, PoE+: 50—57V |
ESD/EMP Protection | Air: ± 16kV, contact: ± 12kV |
Shock and Vibration | ETSI300-019-1.4 Standard |
Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
Ambient Operating Humidity | 10 to 90% noncondensing |
Certifications | CE, FCC, IC |
Layer 2 Features | IGMP snooping, STP/RSTP, Port isolation, Storm control, Voice VLAN, Port mirroring, LACP port aggregation, Multicast/broadcast rate limiting, MAC address blocking, Flow control, 802.1X control, Jumbo frames, Proprietary loop protection, DHCP snooping/guarding, Egress rate limit, LLDP-MED, Port restricted by MAC, Device isolation with ACLs |
Layer 3 Features | None |
LEDs | System: Status, Ethernet: PoE, Speed/Link/Activity, SFP: Link/Activity |
